21/42 Inch High Speed Direct Warping Machine In Textile Warping Machine ZYTT

21/42 Inch High Speed Direct Warping Machine In Textile Warping Machine ZYTT
21/42 Inch High Speed Direct Warping Machine In Textile Warping Machine ZYTT 21/42 Inch High Speed Direct Warping Machine In Textile Warping Machine ZYTT 21/42 Inch High Speed Direct Warping Machine In Textile Warping Machine ZYTT 21/42 Inch High Speed Direct Warping Machine In Textile Warping Machine ZYTT 21/42 Inch High Speed Direct Warping Machine In Textile Warping Machine ZYTT 21/42 Inch High Speed Direct Warping Machine In Textile Warping Machine ZYTT

Large Image :  21/42 Inch High Speed Direct Warping Machine In Textile Warping Machine ZYTT

Product Details:
Place of Origin: Jiangsu, China
Brand Name: ZYTT
Certification: CE
Model Number: 21/42
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $25,000.00/sets 1-1 sets
Packaging Details: Wooden package
Delivery Time: 30 days
Supply Ability: 100 Set/Sets per Month
Detailed Product Description
Applicable Industries: Manufacturing Plant Showroom Location: India
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: New Product 2022 Warranty Of Core Components: 1 Year
Core Components: PLC, Motor Condition: New
Production Capacity: 100% Power: 11KW
Warranty: 1 Year Key Selling Points: Easy To Operate
Machine Type: Warping Machine Service: Support
Local Service Location: India After Sales Service Provided: Video Technical Support
Port: Shanghai
High Light:

High Speed Direct Warping Machine ZYTT

,

Textile Warping Machines ZYTT

,

warping in textile ZYTT

21/42 High speed direct warping machine
Product Applications
21/42 High speed direct warping machine is our new developed product. The diameter of the beam can be monitored and the tension can be controlled, during warping by micro computer control system, which can make sure the same diameter of the beam group and the length. It is suitable for warping cotton yarn, viscose, blending yarn, polyamide and polyester filament, low elastic polyester fiber, viscose, and short-fiber yarn.
Warp linespeed 100-1000m/min
Warp beam size 21"xФ42"(inch),21"xФ30"(inch),21"xФ40"(inch)
Motor power 11KW AC FC control.
Tension roller Motor with AC FC control
Control way Micro-computer real-time monitoring and display
Copy precision the perimeter error of the same group beam is less than5mm, the tension wave is equal
Max counting range 99999 meters (circles).



Product Features
1.New type, simple operation, intelligent identification, auto-reservation of data.
2. Electronic gear, auto-controlled speed track and auto-controlled inspecting machine and power cutting protection system.
3. According to the mother beam, the sub-beam with same perimeter are to be made.
4.The diameter of the beam can be monitored and the tension is stable
which make sure the same diameter of the beams group and the length.
5. The load and unload of the beam is controlled pneumatically, up and down in line, the motion is stable and position is precise, the break of main shaft adopts pneumatic brakes.
6. The machine can set the beams, I. e. according to the mother beam, the sub-beams with same perimeter and rotations can be made.


21/42 Inch High Speed Direct Warping Machine In Textile Warping Machine ZYTT 0
21/42 Inch High Speed Direct Warping Machine In Textile Warping Machine ZYTT 1
21/42 Inch High Speed Direct Warping Machine In Textile Warping Machine ZYTT 2
Product Features
1.New type, simple operation, intelligent identification, auto-reservation of data.
2. Electronic gear, auto-controlled speed track and auto-controlled inspecting machine and power cutting protection system.
3. According to the mother beam, the sub-beam with same perimeter are to be made.
4.The diameter of the beam can be monitored and the tension is stable
which make sure the same diameter of the beams group and the length.
5. The load and unload of the beam is controlled pneumatically, up and down in line, the motion is stable and position is precise, the break of main shaft adopts pneumatic brakes.
6. The machine can set the beams, I. e. according to the mother beam, the sub-beams with same perimeter and rotations can be made.
