Manual 8 Color 16 Station Automatic Cloth Printing Machine Pajamas Umbrellas

Manual 8 Color 16 Station Automatic Cloth Printing Machine Pajamas Umbrellas
Manual 8 Color 16 Station Automatic Cloth Printing Machine Pajamas Umbrellas Manual 8 Color 16 Station Automatic Cloth Printing Machine Pajamas Umbrellas Manual 8 Color 16 Station Automatic Cloth Printing Machine Pajamas Umbrellas Manual 8 Color 16 Station Automatic Cloth Printing Machine Pajamas Umbrellas Manual 8 Color 16 Station Automatic Cloth Printing Machine Pajamas Umbrellas Manual 8 Color 16 Station Automatic Cloth Printing Machine Pajamas Umbrellas

Large Image :  Manual 8 Color 16 Station Automatic Cloth Printing Machine Pajamas Umbrellas

Product Details:
Place of Origin: Jiangsu, China
Brand Name: ZYTT
Certification: CE
Model Number: 8 color/16 station
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $25,000.00/sets 1-1 sets
Packaging Details: steel pallet
Delivery Time: 30 days
Supply Ability: 1000 Set/Sets per Month
Contact Now
Detailed Product Description
Plate Type: Screen Printer Applicable Industries: Manufacturing Plant, Printing Shops, Other
Condition: New Usage: Cloths Printer, T-shirts
Automatic Grade: Automatic Color & Page: Multicolor
Voltage: 380V Dimensions(L*W*H): 1700*1100*1560
Weight: 800 KG Max. Print Area: 600*800mm
Warranty: 1 Year After-sales Service Provided: Video Technical Support
Key Selling Points: High-accuracy Machinery Test Report: Provided
Video Outgoing-inspection: Provided Warranty Of Core Components: 1 Year
Core Components: Motor, PLC, Engine, Gearbox Model Mode: ZY-SPG-5070/16
Color/Dryer/Station: 8/6/16 Print Color: KCMY
Maximum Print Area Is Max.print Area: 500*700mm Pallet Size: 600*800mm
Air Pressure Is Air Source: ≥0.6Mpa Maximum Output Max.Output: 600pcs/h
Host Power, Power: 6.3Kw Oven Power Each Dryer Unit Power: 13.5Kw
After Warranty Service: Video Technical Support Port: Shanghai
High Light:

8 color automatic screen printing press

,

8 color manual screen printing machine

,

8 color manual screen printing press

Manual 8 color/16 station t shirts Automatic Screen Printing Machine For pajamas, fabrics, cloth, umbrellas
Brief Introduction
This machine is a multi-function rotating automatic screen printing machine, the computerized central control system is a human-computer interface, touch the display screen, all the input command operation functions are displayed in text.The machine adopts imported servo motor drive, strong machine stability, adapt to the requirements of various printing process, and ensure the printing accuracy in ± 0.05mm, the institutional parts are through strict quality management production process, less maintenance, strive for zero fault, simple maintenance, to provide the customer with the best quality, the most affordable, the most practical, the most trusted and the most satisfactory printing mechanical equipment.
 Print Color / Station
8/16
4/10

Maximum print area is Max.print Area
500*700mm
200*300mm

Platform plate area is Pallet Size

600*800mm

Air pressure is Air Source

≥0.6Mpa

maximum output Max.Output
600pcs/h


Main Motor Power
6.3Kw


Each Dryer  Power
13.5Kw


Machine Application
Manual 8 Color 16 Station Automatic Cloth Printing Machine Pajamas Umbrellas 0
Advantage
1. Adopt a new synchronous servo system, with fast transmission speed and good stability. 2. The workbench rotates automatically and each station positioned accurately (± 0.05mm).

Manual 8 Color 16 Station Automatic Cloth Printing Machine Pajamas Umbrellas 1
Company Profile
Manual 8 Color 16 Station Automatic Cloth Printing Machine Pajamas Umbrellas 2
Our Partner
Manual 8 Color 16 Station Automatic Cloth Printing Machine Pajamas Umbrellas 3
Certificates & Exhibitions
Manual 8 Color 16 Station Automatic Cloth Printing Machine Pajamas Umbrellas 4
Packaging & Logistics
Manual 8 Color 16 Station Automatic Cloth Printing Machine Pajamas Umbrellas 5
