This machine is suitable for blanket, paint roller fabric and other kinds of high pile fabric
|
Product Details:
Payment & Shipping Terms:
|
| Applicable Industries: | Manufacturing Plant | Showroom Location: | United States, Italy, Viet Nam, Pakistan, India, Uzbekistan, Iron |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 1 Year |
| Core Components: | PLC, Bearing, Motor, Gear | Condition: | New |
| Automatic Grade: | Automatic | Voltage: | 380V |
| Weight: | 7500 KG | Warranty: | 1 Year |
| Production Capacity: | 98% | Name: | Raschel Warp Knitting Machine |
| Function: | Automatic | Suitable For: | Home Textiles Fabric |
| Product Name: | Textile Fabric Double Needle Bar Raschel Machine | Fabric Type: | Paint Roller Fabric |
| Application: | Textile Industry | Feature: | High Efficiency |
| Number Of Bars: | 5 | Key Words: | High Pile |
| COLOR: | Green | Port: | Ningbo Qingdao Shanghai |
|
Gauge
|
|
E16,E18,E22
|
|
||
|
Working width
|
|
90",100", 110",138"
|
|
||
|
Max Speed
|
|
800RPM(not included special materials and processes
|
|
||
|
Needle Type
|
|
Latch needle block,Individuual latch needle
|
|
||
|
Nunber of bars
|
|
5 ground bars,1separated jacquard bar
|
|
||
|
Distance between knocking-over bar
|
|
10mm-50mm
|
|
||
|
Pattern drice
|
|
Pattern drice
|
|
||
|
Take-up
|
|
Electronic take-up
|
|
||
|
Batching
|
|
Mechanical/Electrical batching(1270mm)
|
|
||
|
Yarn let-off
|
|
EBC,EBA
|
|
||
|
Beams
|
|
21"-30"
|
|
||
|
Main power
|
|
3KW-5.5kw(according to working width
|
|
||
