Adopt oil immersed cam-linkage mechanism; stationary ground bar;EBA let-off;pile height:3-25mm
|
Product Details:
Payment & Shipping Terms:
|
| Applicable Industries: | Manufacturing Plant, Toy Fabric Factory, Blanket Factory | Condition: | New |
|---|---|---|---|
| Product Type: | Raschel, Blanket, Toy Fabric | Type: | RASCHEL |
| Production Capacity: | 800 Rpm Max Speed | Power: | 6000 W |
| Knitting Style: | Warp | Knitting Method: | Double |
| Computerized: | Yes | Weight: | 12000 KG |
| Dimension(L*W*H): | 5900x5500x3300 | Warranty: | 1 Year |
| Key Selling Points: | High Productivity | Gauge: | 16 GG, 18GG, 22GG, 24GG |
| Knitting Width: | 138 Inch | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Marketing Type: | New Product 2020 |
| Warranty Of Core Components: | 1 Year | Core Components: | Pressure Vessel, Motor, Bearing, Gear, PLC, Pump, Engine, Gearbox |
| Name: | Warp Knitting Machine | Function: | Automatic |
| Suitable For: | Blanket,toy Fabric, Decoration | Machine Function: | Knitting |
| Application: | Textile Industry | Feature: | High Efficiency |
| Keyword: | Raschel Machine | Working Width: | 90inch 100inch 110inch 138inch |
| Port: | Ningbo Qingdao Shanghai | ||
| High Light: | Jacquard Blanket Raschel Machines 138 Inch,138 Inch raschel lace machine,raschel lace machine 138 Inch |
||
|
Gauge
|
|
E16 E18 E22 E24
|
|
||
|
Working width
|
|
90inch 100inch 110inch 138inch
|
|
||
|
Speed
|
|
800rpm
|
|
||
|
Needle Type
|
|
Latch needle
|
|
||
|
Nunber of bars
|
|
5 ground bars
|
|
||
|
Distance between knocking-over bar
|
|
6-50mm
|
|
||
|
Batching
|
|
Mechanical/Electrical batching(1270mm)
|
|
||
|
Yarn let-off
|
|
EBC,EBA
|
|
||
