| MOQ: | 1 set |
| Price: | $25,000.00/sets 1-1 sets |
| Standard Packaging: | Wooden package |
| Delivery Period: | 30 days |
| Supply Capacity: | 100 Set/Sets per Month |
| Warp linespeed | 100-1000m/min |
| Warp beam size | 21"xФ42"(inch),21"xФ30"(inch),21"xФ40"(inch) |
| Motor power | 11KW AC FC control. |
| Tension roller | Motor with AC FC control |
| Control way | Micro-computer real-time monitoring and display |
| Copy precision | the perimeter error of the same group beam is less than5mm, the tension wave is equal |
| Max counting range | 99999 meters (circles). |
Product Features
1.New type, simple operation, intelligent identification, auto-reservation of data.
2. Electronic gear, auto-controlled speed track and auto-controlled inspecting machine and power cutting protection system.
3. According to the mother beam, the sub-beam with same perimeter are to be made.
4.The diameter of the beam can be monitored and the tension is stable
which make sure the same diameter of the beams group and the length.
5. The load and unload of the beam is controlled pneumatically, up and down in line, the motion is stable and position is precise, the break of main shaft adopts pneumatic brakes.
6. The machine can set the beams, I. e. according to the mother beam, the sub-beams with same perimeter and rotations can be made.
|
|
